Xserve (Early 2008, Intel Xeon Harpertown)
A1246 · Intel Xserve
0 in collections0 wanted
Have one in your collection? Track it on Orchard.
Start your collection
Identifiers
| Order number | A1246 |
Reference
| Original price | $2,999 – $4,299 |
| Announced | 2008-01-08 |
| Discontinued | 2009-04-07 |
| Max supported OS | Mac OS X Server 10.7.5 Lion |
| Design era | Intel Xserve |
Configurations
| Colors | Anodized aluminum |
| CPU | Quad Intel Xeon E5462 @ 2.8 GHz, Dual Quad Intel Xeon E5472 @ 3.0 GHz, Dual Quad Intel Xeon X5482 @ 3.2 GHz |
| Memory | 2 GB, 4 GB, 8 GB, 16 GB, 32 GB (max) |
| Storage | 3× 3.5″ SATA/SAS hot-swap bays, Up to 3 TB |
| Graphics | ATI Radeon HD 2400 XT (64 MB) |
| OS | Mac OS X Server 10.5.2, Mac OS X Server 10.6.8 |
| Removable media | Slot-loading SuperDrive (optional) |
Physical
| Ports & connectivity | 2× USB 2.0 · 2× FireWire 800 · 2× Gigabit Ethernet · Mini-DVI · DB-9 serial · PCI Express 2.0 slots (2) |
| Dimensions (W×H×D) | 445 × 44 × 711 mm |
| Weight | 14.1 kg |
Known quirks
- Harpertown Xeons brought 45nm quad-core — 8 physical cores in dual-socket builds
- Jumped from FireWire 400 to dual 800 — faster target-disk-mode rescues
- Fully-buffered DIMMs run hot and need careful memory population rules
- Firmware-locked to Apple-branded heatsinks for proper thermal trip points
- Last Xserve to support 32-bit EFI — 2009 went 64-bit EFI
