Desktop · 1993ObsoleteRare · 65
Macintosh Quadra 660AV
M9020 · Quadra era
0 owned0 wanted
Have one in your collection? Track it on Orchard.
Start your collection
Identifiers
| Order number | M9020 |
Reference
| Original price | $2,489 |
| Announced | 1993-10-21 |
| Discontinued | 1994-09-12 |
| Max supported OS | Mac OS 8.1 |
| Design era | Quadra era |
Configurations
| Colors | Platinum |
| CPU | Motorola 68040 @ 25 MHz, AT&T 3210 DSP |
| Memory | 4 MB, 8 MB, 16 MB, 68 MB (max) |
| Storage | 80 MB SCSI HDD, 230 MB SCSI HDD, 500 MB SCSI HDD |
| Graphics | Built-in 16-bit video |
| Operating system | System 7.1, System 7.1.1, System 7.1.2, System 7.5, System 7.5.1, System 7.5.2, System 7.5.3, System 7.5.5, Mac OS 7.6, Mac OS 7.6.1, Mac OS 8.0, Mac OS 8.1 |
| Removable media | 1.4 MB floppy (FDHD), CD-ROM |
Physical
| Ports & connectivity | ADB (2) · DB-25 SCSI · 2× GeoPort RS-422 · 3.5mm audio in · 3.5mm audio out · AAUI Ethernet · Composite video in/out · S-Video in/out · PDS |
| Dimensions (W×H×D) | 305 × 107 × 381 mm |
| Weight | 4.1 kg |
Known quirks
- Rebrand of Centris 660AV — same M9020 model number and hardware
- Smaller sibling to Quadra 840AV — same DSP audio/video features
- PlainTalk speech recognition continues here
- DSP runs warm — thermal service points are the same as 840AV
