Macintosh Quadra 630
M3076 · Quadra era
0 in collections0 wanted
Have one in your collection? Track it on Orchard.
Start your collection
Identifiers
| Order number | M3076 |
Reference
| Original price | $1,199 |
| Announced | 1994-07-18 |
| Discontinued | 1996-04-01 |
| Max supported OS | Mac OS 8.1 |
| Design era | Quadra era |
Configurations
| Colors | Platinum |
| CPU | Motorola 68040 @ 33 MHz |
| Memory | 4 MB, 8 MB, 12 MB, 36 MB (max) |
| Storage | 250 MB IDE HDD, 500 MB IDE HDD |
| Graphics | Built-in video (1 MB VRAM) |
| Operating system | System 7.1, System 7.1.1, System 7.1.2, System 7.5, System 7.5.1, System 7.5.2, System 7.5.3, System 7.5.5, Mac OS 7.6, Mac OS 7.6.1, Mac OS 8.0, Mac OS 8.1 |
| Removable media | 1.4 MB floppy (FDHD), CD-ROM |
Physical
| Ports & connectivity | ADB · IDE (internal) · 2× RS-422 Mini-DIN-8 serial · 3.5mm audio in · 3.5mm audio out · LC PDS · Comm slot · Video-in (optional) |
| Dimensions (W×H×D) | 305 × 76 × 381 mm |
| Weight | 3.6 kg |
Known quirks
- First Mac to use IDE instead of SCSI — cheaper drives but slower
- 68LC040 lacks FPU — some software won't run
- TV tuner card was optional — made it an early home media PC
- PRAM battery leak and logic-board cap aging
