iPod Mini (2nd gen)
A1051 / M9800 / M9802 / M9803 / M9804 / M9805 · iPod Mini
0 in collections0 wanted
Have one in your collection? Track it on Orchard.
Start your collection
Identifiers
| Order number | A1051 / M9800 / M9802 / M9803 / M9804 / M9805 |
Reference
| Original price | $199 – $249 |
| Announced | 2005-02-23 |
| Discontinued | 2005-09-07 |
| Max supported OS | iPod firmware 4.x |
| Design era | iPod Mini |
Configurations
| Colors | Silver, Pink, Blue, Green |
| Processor | PortalPlayer PP5020 @ 80 MHz |
| Memory | 32 MB SDRAM |
| Storage | 4 GB Microdrive, 6 GB Microdrive |
| Display controller | Built-in LCD controller |
| Display | 1.67″ monochrome LCD (138×110) |
| Firmware | iPod firmware 4.x |
Physical
| Ports & connectivity | 30-pin dock · USB 2.0 via dock cable · 3.5mm headphone · Click Wheel |
| Dimensions (W×H×D) | 51 × 91 × 13 mm |
| Weight | 102 g |
Known quirks
- Brighter backlight vs mini 1G; minor revision otherwise
- Killed almost immediately by the Nano's arrival
- Colors shifted — gold dropped, others got more saturated
- Microdrive reliability unchanged; still the weak point
